6.2 HMI Screens
Start
2019/10/20 10:33
Wallbox 4.0
You will return to this screen from any other due to inactivity
(30 sec).
By default, the date and time will be displayed, and "Wallbox
4.0".
The backlight will be off by default.
LEDs Color
Green.
Button Action
It activates backlighting with a 30s inactivity time.
The screen shows Swipe card through reader.
RFID Action
If the user is authenticated to Starting Session. Otherwise, to
Nor Authorized User.
EV Action
- “free_charging_mode” = on and change to ‘B’ or ‘C’ state.
Starts the preferred recharge. The screen will depend on
the type of recharge:
o Programmed charge: Waiting for charging start.
o Immediate charge: Charging in progress.
- “free_charging_mode” = off.  None.
RFID Authentication
SWIPE CARD
THROUGH READER
Indication for authentication before login.
LEDs Color
White.
Button Action
ESC  Goes to Start screen.
RFID Action
Authentication is performed:
- Failed authentication  Nor Authorized User.
- Successful authentication 
- without charging session  Main menu without
recharging.
- open charging session 
Main menu during
recharging.
EV Action
- Open charging session:
o Changes to ‘A’ state Stopping Session.
o Changes to other states  None.
- Without charging session  None.
