Starting Session
STARTING
SESSION
Login authentication message of a user through RFID. Only
displayed if it is a back-end authentication and if no charge is
active. In case of active charge, the back-end is never asked,
only verified that it is the same card that started the charge
process.
LEDs Color
White.
Button Action
ESC  Goes to Start screen.
RFID Action
Authentication is performed:
- Failed authentication  Nor Authorized User.
- Successful authentication 
- without charging session  Main menu without
recharging.
- open charging session 
Main menu during
recharging.
EV Action
- Open charging session:
o Changes to ‘A’ state Stopping Session.
o Changes to other states  None.
- Without charging session  None.
Nor Authorized User
NOT AUTHORIZED
A message is displayed indicating that the card is not
authorized at the Recharging Point.
After about 5s, it will return to Start.
LEDs Color
White.
Button Action
ESC  Goes to Start screen.
RFID Action
None.
EV Action
- Open charging session:
o Changes to ‘A’ state Stopping Session.
o Changes to other states  None.
- Without charging session  None.
