Main menu without recharging
CHARGE NOW
PROGRAM CHARGE
CONFIGURATION
GENERAL.INFO
To see all the options, you must use the scroll buttons. The
setting option is shown for all users, the available options differ
depending on the user.
LEDs Color
White.
Button Action
ESC  Goes to Start screen.
↑↓  Line selection.
OK  Depending on the line where the cursor is, it goes to a
different screen:
- CHARGE NOW: Plug Connector.
- PROGRAM CHARGE: Establish programmed charge.
- CONFIGURATION: Configuration.
- GENERAL.INFO: General info.
RFID Action
None.
EV Action
None.
Main menu during recharging
STOP CHARGE
GENERAL.INFO
Using the scroll buttons, you can access both options.
LEDs Color
White.
Button Action
ESC  Goes to Charging in progress screen.
↑↓  Line selection.
OK  Depending on the line where the cursor is, it goes to a
different screen:
- STOP CHARGE: goes to Summary session screen.
- CONFIGURATION: Configuration.
- GENERAL.INFO: General info.
RFID Action
None.
EV Action
Changes to ‘A’ state

Stopping Session.
Changes to other states  None.
