Establish programmed charge
CHARGE
Start 01:00
End 07:00
This screen will display by default the start and end times of
charging that have been set in the last session and the option
to start charging (CHARGE).
LEDs Color
White.
Button Action
ESC

You go to previous editable position. If we are in
CHARGE goes to Main menu without recharging.
↑↓  Increase/decrease, for the time setting, the
value on
which the cursor is placed.
OK 
It is validated and goes to the subsequent editable
position. If the cursor is in the last position, the set values are
saved and goes to
Waiting for charging start, if the EV is
connected, or goes to Plug connector if it is not connected.
If no time is selected-> Invalid range.
RFID Action
None.
EV Action
None.
Invalid range
INVALID RANGE
This screen will be displayed when neither start nor end time
is set on a programmed charge.
LEDs Color
White.
Button Action
ESC  Returns to Establish programmed charge.
OK  Returns to Establish programmed charge.
RFID Action
None.
EV Action
None.
Plug connector
PLUG CONNECTOR
Screen to detect the EV. When it is detected, it starts the
charging process.
If the EV is already connected, this screen does not appear.
LEDs Color
Blinking yellow.
Button Action
ESC  Goes to Start screen.
RFID Action
None.
EV Action
Changes to 'B' or 'C' state:
- Programmed charge: Waiting for charging start.
- Immediate charge: Charging in progress.
