5EVM-D: Electric Vehicle Home AC Charging Station
© ZIV APLICACIONES Y TECNOLOGÍA, S.L.U. 2020
Charging in progress
Energy 12.43 kWh
Power 00.00 kW
Time 05h 36m
Data from the charging in progress is displayed with a refresh
time of 1 second.
LEDs Color
- Blue

when the vehicle demands charge (‘C’ state).
- Blinking blue  when the vehicle does not demand
charge ('B' state).
Button Action
ESC  Goes to Main menu during recharging screen.
RFID Action
Stopping Session.
EV Action
- Changes to ‘A’ state  Stopping Session.
- Changes to ‘B’ or ‘C’ state  None.
Waiting for charging start
WAITING START
Start 02:00
End 07:00
In this screen, for a deferred charge, the programmed Start
and End times are shown.
When the actual time is the same as the Start time, charging
will begin
( Charging in progress ) and will end at the
programmed End time.
LEDs Color
Blinking blue.
Button Action
Swipe card through reader.
RFID Action
Main menu during recharging.
EV Action
- Changes to ‘A’ state  Stopping Session.
- Changes to ‘B’ or ‘C’ state  None .
