Stopping Session
STOPPING
SESSION
This screen appears when a user has been authenticated
during a charging process or by disconnecting the EV.
It will last about 5s and then, it will go to Summary session.
LEDs Color
White.
Button Action
ESC  Start.
RFID Action
None.
EV Action
None.
Summary session
SUMMARY SESSION
Energy 12.25kWh
Time 1h44m
This screen is displayed after logging out.
Afterwards, it goes to Start.
LEDs Color
White.
Button Action
ESC  Goes to Start screen.
RFID Action
None.
EV Action
Changes to ‘A’ state  After 30 seconds goes to Start.
Changes to ‘B’ or ‘C’ state  None.
Configuration
Date/time
Users
Charge mode
Contracted power
Language
On this screen, the configuration options will be displayed by
means of the cyclic menu. All the options are displayed using
the scroll buttons. The available options differ depending on
the user:
- Master Card: displays all options.
- Client Card: only the configurable options enabled for the
client user, taking into account that:
o Charge mode: it will be enabled if the "free charge"
mode is configured.
o Contracted power: if the Load Balancing (Home AC)
function is enabled.
LEDs Color
White.
Button Action
ESC

Main menu without recharging.
↓↑  Line selection.
OK  Depending on the line where the cursor is, it goes to a
different screen:
- Date/Time: Configure date/time.
- Users: Users/cards management.
- Charge mode: Preferred charge mode.
- Contracted power (only for equipment with Load
Balancing function): Contracted power .
- Language: Language selection.
RFID Action
None.
EV Action
None.
