Table 1: Definition of S900 Terminal Pin Layout
J 7, 9pin connector
1
st
NC2 Connect to Alarm NC terminal
2nd COM2 Connect to Alarm COM terminal
3rd NO2 Connect to Alarm NO terminal
4th NC1 Connect to Lock NC terminal
5th COM1 Connect to Lock COM terminal
6th NO1 Connect to Lock NO terminal
7th Button Connect to Release button
8th GND For Door sensor and release button
9th Sensor Connect to Door sensor
J1, 2Pin connector
1st GND Connect to Power GND
2nd +12V Connect to Power +12v
J2, 4Pin connector
1st RJ45-6 Connect to RJ45 plug wiring 6
2nd RJ45-3 Connect to RJ45 plug wiring 3
3rd RJ45-2 Connect to RJ45 plug wiring 2
4th RJ45-1 Connect to RJ45 plug wiring 1
