ZKaccess C3-200 User Manual

Specifications
20
Communication RS485, TCP/IP
Baud Rate for RS485 9600-115200
Power Supply 12V DC, 3A
Card Holders Capacity 30,000
Log Events Capacity 100,000
LED Indicator Indication for communication, power, status and prox card
Environment
32-113 °F (0-45 °C)
Operating Humidity 20% to 80%
Number of doors controlled Four Door (four door one way two door two way)
Number of readers supported 4
Types of readers supported 26-bits WIEGAND, others upon request
Number of Inputs 6 (2 Exit Device, 2 Door Status, 2 AUX)
Number of Outputs 4 (2- Form C relay for lock and 2- Form C relay for Aux output)
Weight 7.8lbs (3.55kg)
Enclosure Stainless Steel
Mounting Wall Mount
Dimensions (Bundle Only) 15.7in. × 3.56in.× 13.0in 400mm(L) X 90.5mm(W) X 330mm(H)
Dimensions ( Board Only) 6.30in. X 4.17in. 160mm(L)X 106mm(W)
CPU 32 bit 400MHz
RAM 32MB
Flash 128MB
Certified
