Wire Legend
9
Detector Infrared sensors #1Exit Switch #1Card Reader
#2 K1-1 Exit Switch
#2 Card Reader
12V
Power Supply
Normal Close Lock
Normal Open Lock
Alarm
RS485 Convertor
LAN Cable
Floodlight
12V DC
Power
DC
