ZKaccess TF1700 Installation Guide

16
TF1700 & ZKAccess CLASSIC 3.5 software INSTALLATION GUIDE
Aux. Input Connection
SN 000000000000
Purple
Brown
White
Black
Gray
Blue
Red
Yellow
Orange
Green
: : : :
+12V
GND
IWD1 IWD0
RLED
GLED
BEEP
WD0 WD1
GND
485+
485-
+12V
GND
Red
Black
White
Green
Blue
Gray
Purple
Green
White
Black
Blue
Yellow
Red
Black
BELL-
BELL+
SEN
GND
BUT
NO1
COM1
YNC1
NO2
COM2
RJ45-1 RJ45-2 RJ45-3 RJ45-6
Bell LOCK Alarm Ethernet
Power485WG-OutReader
Fingerprint Access Control
Manufacturing license No: 75569364-2
SBTS Registered No: H0201
Power Supply DC 12V == 3A
Operating Environment Temperature: 0ºC-45ºC
ISO9000 :
2008 CE FC RoHS
69370226
PIN DESCRIPTION WIRE
1 BELL- Purple
2 BELL+ Brown
3 SEN White
4 GND Black
5 BUT Gray
Sensor
EXIT
No Touch
Do not use
Exit Button Connection
