ZKTeco AL10B Installation Instruction

Note: Please refer to the above picture to adjust the direction of strike plate F and latch D.
1. Check the door thickness and prepare the corresponding mounting
hardware package.
2. Check door opening direction.
F
F
F
F
D D
D
D
30~38 56 20 10 25
39~46 64 30 10 30
47~54 72 40 10 40
H Spindle Length
(mm)
J Screw Length
(mm)
M Screw Length
(mm)
L Screw Length
(mm)
Door Thickness
(mm)
4
Door Preparation
Left inward Right inward
Left outward Right outward
Standpoint
