6.Insert batteries.
K
E
G
F
7.Mark and drill holes for the strike.
8. Test the lock by rotating the back handle and using the mechanical
Key (A).
Note:
1) When the door is locked and the clutch is idle, the front handle can be
turned, but the door will remain locked.
2) When you are inside the door, turn the handle upward to lock the deadbolt
for more security. When you go out, verify your fingerprint first, and then turn
the handle up to lock the door for the safety of your property.
8
58(mm)
(2-36/127")
(215/254")
(70/127")
(1-48/127")
2(mm)
(10/127")
14(mm)
(70/127")
35(mm)
14(mm)
(1-18/127")
29(mm)
21.5(mm)
