1) Align the template along the vertical center line of the
latch(D) at the desired handle height, and tape it to the door.
2) Mark the holes first, and then start drilling.
1.Drill holes on the door. 2.Install the latch (D).
E
centerlineofthe
handle
h
desired handle
height
Installation
5
Note Installing the mortise(D) on the door :
by inserting screws(E).
30~60mm
60mm
