ZKTeco MB20-VL User Manual

2
2.Device Installation
①Attach the mounting template sticker to the wall, and drill holes according to
the mounting paper.
②Fix the back plate on the wall using wall mounting screws.
③After passing the wires through the wiring hole and connecting them to the
device, and then attach the device to the back plate from top to bottom.
④Fasten the device to the back plate with a security screw.
Install on the wall
1 2
43
1.1m
①
②
Baseline

ZKTeco MB20-VL Specifications

General

Brand	ZKTeco
Model	MB20-VL
Category	Touch terminals
Language	English
