ZKTeco UHF10F Pro Reader - Specifications

U H F10 P r o R e a d e r
Us er Ma nu a l
P a g e | 8
C o p y r i g h t © 2021 Z K TE C O C O ., L T D . All r ig h t s r es er v ed .
3 Specifications
Model
UHF10F Pro
Reading Distance
10 to 20meters (Hand-held test)
Actual scenario test is around 8m
AntennaGain
12dBi
Dimension
445*445*67.5mm
Weight
3kg
Power
1.2 to 4.5 W
Frequency
919.5-923.0MHz (supports adjustment)
Communication
interface
Wiegand; RS485; USB Configuration
parameters(Wiegand, RS485 requires one
of the two
options)
Interface Protocol
EPC global UHF Class 1 Gen 2 / ISO 18000-6C
Working Mode
Read Always (Default) & Read by Trigger
Output Power
19dBm to 30dBm
Protection Class
IP66
WorkingVoltage
DC 9 to15V
Working Temperature
and Humidity
-20℃ to 65℃, <85%
Storage Temperature
and Humidity
-20℃ to 80℃, <85%
RS485 Communication
Optional baud rate (9600, 19200, 38400,
57600,
115200). The default is 115200
