Zline DW-WM-18 User Manual

17
Step 9: Securing the Dishwasher
You must fix the dishwasher to the countertop or cabinet side walls for additional
stability.
If the countertop is made of wood or the material will not be damaged by drilling,
follow the instructions in 1 below.
If the countertop is made of granite, marble, or any other material that can be
damaged by drilling, follow the Instructions in 2 below.
1. Put a large towel into the bottom of the dishwasher to prevent wood shavings or a
dropped screw from falling into the dishwasher.
Carefully drill screw holes into the counter top bottom by passing the drill bit through
a screw hole in each bracket, and then drilling into the counter top bottom beneath.
Make sure the hole you drill is smaller than the diameter of the screw.
Firstly, put the installation bracket into the slot of the side plane and tighten to the
dishwasher with screw ST3.5*9. Secondly, insert the provided screws into the
brackets, and then tighten to secure the dishwasher to the counter top.
2. Put a large towel into the bottom of the dishwasher to prevent wood shavings or a
dropped screw from falling into the dishwasher. Remove the adjustment cap with the
tip of a screwdriver. The caps are just inside the tub near the middle of the tub an both
sides(Figure 9 on the next page).
Drill a hole into the sides of the kitchen cabinet on both sides by carefully passing a
drill bit through the screw holes exposed by the removal of the spacer caps, and then
drilling into the cabinet side beneath.
Make sure the hole you drill is smaller than the diameter of the screw.
Also make sure the drill bit does not strike the sides of the spacer cap holes. Firstly, put
the installation bracket into the slot of the side plane and tighten to the dishwasher
with screw ST3.5*9. Secondly, insert the provided screws into the holes, and then
tighten to secure the dishwasher to the cabinet. Make sure the tub is not distorted by
pressure from the screws.
If the tub is distorted, loosen the screws a little.
Replace the tub spacer caps.
installing the dishwasher

Zline DW-WM-18 Specifications

General

Style	built-in dishwashers
Color	white matte, matte white
Load Capacity	16
Number of Cycles	6
Options/Settings	energy save, quick wash, normal, rinse, eco wash, heavy wash, sanitary, high temperature wash, glass, heat dry option
Drying Type	heated drying
Noise level	40 decibels adjusted
Control Type	touchpad
Delay Start	yes
Number of Racks	2
Sanitize Settings	no
Annual Energy Consumption	234 kilowatt hours
Voltage	120 volts

Weight and Dimensions

Depth	23 inches
Height	32 1/2 inches
Width	17 3/4 inches
Net Weight	73.7 pounds
