Zline DW-WM-18 User Manual

20
Step 10: Connecting the Drain Hose Continued
To prevent leaks or drainage problems, make sure the drain hose is not damaged,
kinked, or twisted.
8. Do not cut the wrinkled area of the drain hose to fit the size. When arranging the
drain hose, take caution to avoid contact with sharp edges of the cabinet or under-
sink.
Figure 12: Secure the drain hose to the sink wall using cable ties or other fastening
materials. Otherwise, the drain hose may bend at the end causing a drainage
problem or excessive supply of water.
installing the dishwasher
WARNING
Figure 11 Figure 12
Be careful when cutting off the end of the drain hose as there is
a risk of injury. Clean around the sink’s drain connection so that
it does not damage the hose. Check for any foreign items in the
drain hose and remove them.
When arranging the drain hose, make sure the drain hose is not
cut, torn, or broken by any sharp edges of the floor, the product
itself, or the cabinet. A damaged drain hose causes a leak.
Figure 13

Zline DW-WM-18 Specifications

General

Style	built-in dishwashers
Color	white matte, matte white
Load Capacity	16
Number of Cycles	6
Options/Settings	energy save, quick wash, normal, rinse, eco wash, heavy wash, sanitary, high temperature wash, glass, heat dry option
Drying Type	heated drying
Noise level	40 decibels adjusted
Control Type	touchpad
Delay Start	yes
Number of Racks	2
Sanitize Settings	no
Annual Energy Consumption	234 kilowatt hours
Voltage	120 volts

Weight and Dimensions

Depth	23 inches
Height	32 1/2 inches
Width	17 3/4 inches
Net Weight	73.7 pounds
