Zline DW-WM-18 User Manual

23
Step 12: Completing the Installation Continued
6. Install the decoration door to the outer door of the dishwasher.
Install the hook and brackets on the decoration door, see figure 17.
Put the hook into the slot of the outer door, see figure 18.
Fix the decoration door onto the outer door with the correct screws and
bolts, see figure 19.
7. Adjust the tension of the door spring.
The door springs are set at the factory to the proper tension for the outer
door. If the decoration door is installed, you will have to adjust the door
spring tension.
Rotate the adjusting screw to drive the adjustor to strain or relax the steel
cable, see figure 20.
Door spring tension is correct when the door remains horizontal in the fully
opened position, yet rises to a close with the slight lift of a finger.
installing the dishwasher
Figure 18Figure 17 Figure 19
Figure 20

Zline DW-WM-18 Specifications

General

Style	built-in dishwashers
Color	white matte, matte white
Load Capacity	16
Number of Cycles	6
Options/Settings	energy save, quick wash, normal, rinse, eco wash, heavy wash, sanitary, high temperature wash, glass, heat dry option
Drying Type	heated drying
Noise level	40 decibels adjusted
Control Type	touchpad
Delay Start	yes
Number of Racks	2
Sanitize Settings	no
Annual Energy Consumption	234 kilowatt hours
Voltage	120 volts

Weight and Dimensions

Depth	23 inches
Height	32 1/2 inches
Width	17 3/4 inches
Net Weight	73.7 pounds
