Page 11
ENGLISH
Owner’s Manual
|
Zodiac
®
DC33 Pool Cleaner
3. Thread the outer extension tube onto the cup
assembly and tighten (see Figure 11).
4. Verify the thrust washer is still in place inside
the handnut. Insert the engine into cleaner body,
slide the handnut over the engine extension tube
and tighten (see Figure 12).
5. Make sure the extension tube
swivels freely by spinning it (see Figure 13).
Storage and Winterizing
Never coil the hose. Store the DC33 cleaner out of direct sunlight. When storing for the winter, drain all water
from the cleaner. Remove all connectors and adapters from the dedicated suction line or skimmer. Store the disc
flat, and hose sections disconnected, drained and straight.
Figure 11
Figure 13
Figure 12
