Zodiac G2 User Manual

Parts list
4
10
1
2
3
5
6
7
8
9
11
12
13
14
15
16
Ref. CODE DESCRIPTION QUANTITY
1 W70291 Body 1
2
W69721 Flexible foot (blue) 1
3
W69911 Disc 1
4
W56525 Internal extension pipe 1
5
W81710 Diaphragm 1
6
W81600 Holding ring 1
7
W70293 External extension pipe 1
8 W74000P Compression ring 1
9
W70401 Diaphragm cartridge 1
10
W69720P Deflector wheel (large) 1
11
W41710 Hose adaptor 1
12
W70335P Pool Pulse 1
13
W69657 Weir adaptor 1
14
W60055P Automatic control valve 1
15
W83353P Hose weight 1
16
W69130 Set of 6 x 1 m blue pipes 1
G2 2010.qxd 23/02/10 9:30 Page 13

Zodiac G2 Specifications

General

Pool Type	In-ground
Debris Type	Small to medium
Warranty	1 year
Power Source	Filtration System
Cleaning Coverage	Floor and walls
Pool Size	Up to 40 feet
