5.4.Thecleanerproducesajetofwaterbutdoesnotmove
•Removethewheels.
•Checkthatnodebrisisstuckinthewheelcogs;removeanydebrisfound.
•Start‐upthecleanerandcheckthatthecogsturn beforethecleanerstops.
5.5.Thecleanermovesuptothewaterlineandsucksinair
•Carryoutthestepsinchapter3.3andcheckthattheproblemissolved.
Ifthe problempersists,removethe cleaner cover,then removethe2  screwsthat 
maintaintheplate(fittedwithhinges)thatfixittothecleaner.Removetheplate.

•Removethepolystyrenefloaterandthenfitthepl
atewiththehinges. Fitthefilter
andthenthecoverontothecleanerandcheckthattheproblemissolved.

5.6.Rightturnisnotefficient

•Theright turnisthefirstrotationofthecleaneratthebeginningofthecycle.
Itcanthereforebecheckedduringthefirstminuteoftheappliance'soperation.
If the cleaner does not turn, check that the small stirrup under the cleaner
pivotsfreelyandremoveanydebristhatmightbebl
ockingit.
Make sure that the roller is not worn; if itis worn,  replace it. If the problem
persistscontactyourreseller.



•Generalcleanerbehaviour:








5.7.Leftturnisnotefficient

•Generalcleanerbehaviour:









5.8.Thecablegetstangled

•Checkthatthecleanerr otatescorrectly(§5.6and5.7).



•Donotunrolltheentirelengthofthecableintothepool.

•Placetherequiredlengthofcablein thepoolandplacetherestonthesideofthepool.
Rotationcorrect
Rotationinefficient.
Thecleaneristooheavy,contactyourresellerto
addafloaterunderthecover.
Rotationcorrect Rotationinefficient.
Thecleaneristoolight.Removetheflo aterasindicatedin
Chapter5.5
.Checktherotationagain,iftheproblempersists,
contactyourreseller
