Figure 40. Tyre Replacement Orientation
1
I
N
S
I
D
E
Towards
Body
I
N
S
I
D
E
I
N
S
I
D
E
4. Push one side of the tyre on to the wheel and
ttheribofthetyreinthegrooveofthewheel
(Figure 41).
2
Figure 41. Start on One Side of the Tyre
5. Work the tyre onto the wheel and verify the
rib of the tyre is positioned properly within the
groove of the wheel (Figure 42).
3
Figure 42. Work the Tyre On Around the Wheel
6.
Push and position the rib of the inner side of
the tyre in the groove of the wheel (
Figure 43ß).
If needed, turn the wheel gently to help with
installation.
4
Figure 43. Push the Tyre into Place on the Wheel
H0516700_REV C
20
