Power supply Static current
DC 3V (AA 1.5V LR6 Batteries x2) ≤30uA
Alarm current Detection scope
≤15mA 8m / 110°
Operating distance Radio-frequency
≤80m (in open area) 315MHz/433MHz (±75kHz)
Housing material Operating conditions
ABS Plastic Temperature : -10°C~55°C
Relative Humidity: ≤80% (non-condensing)
Detector dimensions Bracket dimensions
107x53x32 mm 52x30x26.5 mm
WIRELESS DOOR / WINDOW CONTACT
The detector door/ window is composed of a transmitter and a sensor magnet. When the two parts
are separated, it sends a signal to the alarm panel to trigger the siren and the phone call.
LED indicator
Transmitter Magnet
Install the Wireless Door/Window Contact
Open the case by pressing and make slide the cover.
Then, remove the battery activation strip.
Mount the sensor on the door frame and the magnet on the door.
Make sure the magnet is on the right side of the transmitter.
Place the transmitter in the desired location, mount the magnet
no more than 1cm away from the transmitter and secure the
transmitter and magnet with double-sided tapes or screws.
Avoid mounting sensors in areas with a large quantity of metal
or electrical wiring, such as a furnace or utility room.
