Zoeller X70 Series User Manual

6
© Copyright 2018 Zoeller
®
Co. All rights reserved.
All installations must comply with all applicable electrical and plumbing codes, including but not limited to the Na-
tional Electrical Code, local, regional and/or state plumbing codes, etc.
Typical Packaged Duplex Grinder Pump Station
FIGURE 5.
SK2843
(36" MINIMUM)
SHUT-OFF VALVE
2" DISCHARGE PIPE
3/4" GUIDE RAILS
CHECK VALVE
WEEP HOLE
NON-SPARKING
RAIL SYSTEM 1 1/4" X 2"
ANTI-FLOATATION RING
WEIGHTED FLOAT SWITCHES
LEAD PUMP "OFF" FLOAT
LEAD PUMP "ON" FLOAT
ALARM FLOAT
LAG PUMP "ON" FLOAT
INLET FITTING
(SHIPPED LOOSE)
TO CONTROL PANEL
28" MIN. OR PER STATE
AND LOCAL CODES
HATCH COVER
HATCH COVER
STEEL
ALUMINUM
GAS TIGHT
CONTROL PANEL - INSTRINSICALLY SAFE
(FIELD INSTALLED)
LIFTING CABLE
ELECTRICAL CONDUIT COUPLING
