Zonar V3 - Installation Best Practices; Cable Bend Radius and Grommet Use; GPS Antenna Mounting Considerations

INCORRECT
• Bend radius too tight
• Hole has sharp edges
• Hole has no grommet
CORRECT
• Bend radius adequate
• Hole has grommet
• Use Zonar supplied screws to prevent scratches
to 2010
• Allow a minimum of 6 inches from
any edge or ledge
• Drill hole size: 1/2” (.500”)
• Grommet 3/8” (.375”) I.D.
• Drill, deburr, grommet, weather
seal, cable thru hole as required
For Non-Magnetic Surfaces -
Optional GPS Antenna Mount
Plate & Screws
1” - 2”
Recommended
22
INSTALLATION EXAMPLE
