Zonar V3 - V3 Pin Configuration; Connector Port Identification

1. External GPS antenna (Optional)
2. 4 Pin Power Input
3. 6 Pin Accessory
- ZPass™
- Virtual Trainer
4. 8 Pin GPS Vehicle Mount (Optional)
5. 12 Pin Discrete Input/Output (Optional)
6. 10 Pin ECM input (JBus 1708/1939 & OBDII equipped vehicles)
Fig. 9-1
V3™ PIN CONFIGURATION
