02
Installation
Zonecheck should be installed by a competent fire sprinkler installer and wired up by a qualified electrician.
1. Contact building management to inform them of the proposed works.
2. Isolate and drain down selected zone.
3. Orientate the Zonecheck in accordance with the diagrams in this booklet.
4. Install the Zonecheck with two approved grooved couplings (not supplied).
5. Double check that the sprinkler flow arrows on Zonecheck are facing the correct
direction (see diagrams included in this booklet).
6. Fit the key-switch to the wall in a suitable location that is easy to reach from floor
level.
7. Wire the Zonecheck pump and flow-switch to the key-switch in accordance with
the diagrams in this booklet.
8. Wire the flow-switch to the appropriate fire-detection panel in accordance with
the diagrams in this booklet.
9. Wire the appropriate power supply to the key-switch.
Proceed to Commissioning instructions.
DO NOT ATTEMPT TO RECONFIGURE.
TAMPERING WILL VOID THE WARRANTY!
