Zoom F1 - Providing Power with AC Adapter

11
Specications
Recording media microSD/microSDHC cards
(Class 4 or higher, up to 32 GB)
Recording formats WAV 44.1 kHz/16-bit, 48 kHz/16-bit, 48 kHz/24-bit, 96 kHz/24-bit
Mono/stereo BWF format supported
MP3 48 kbps, 128 kbps, 192 kbps, 256 kbps, 320 kbps
Mono/stereo ID3v1 tags supported
Display 1.25" monochrome LCD (96×64) with REC LED (red)
Inputs MIC IN ZOOM mic capsule input
MIC/LINE IN Connector 3.5 mm stereo mini
(with screw lock)
Supports plug-in power (2.5 V)
Input gain −12 dB – +36 dB
Input impedance Input impedance: 2 kΩ or more
Output PHONE OUT Connector 3.5 mm stereo mini
(with screw lock)
Maximum output level 11 mW + 11 mW (into 32Ω load)
USB microUSB
Mass storage
operation
USB 2.0 High Speed
Audio interface
operation
USB class compliant
44.1/16-bit, 48kHz/16-bit, 2-in/2-out
Transfer method: asynchronous
Power 2 AAA batteries (alkaline, NiMH or lithium)
AC adapter (ZOOM AD-17): DC 5V/1A
Estimated continuous
recording time using
batteries
With SGH-6 mono shotgun mic capsule connected (48 kHz/24-bit, mono)
Alkaline batteries: about 6.5 hours
NiMH batteries 750 mAh): about 6 hours
Lithium batteries: about 11 hours
When using lavalier mic (48 kHz/24-bit, mono, plug-in power on)
Alkaline batteries: about 10 hours
NiMH batteries 750 mAh): about 9 hours
Lithium batteries: about 16 hours
• The above values are approximate.
• Continuous battery operation times were determined using in-house testing methods.
They will vary greatly according to use conditions.
External dimensions 64.0 mm (W) × 79.8 mm (D) × 33.3 mm (H)
Weight (main unit only) 120 g
