Zoom F1 Quick Guide

5
Input and output settings
Adjusting input levels
Adjust the level of the signal input to the .
• Adjustsothatthepeaklevelstaysaround−12dB.
• IftheRECLEDashes,thesoundcouldbecomedistorted,solowertheinputlevel.
HINT
■
When using a mic capsule
1.
Turn on the mic capsule to adjust the input level.
■
When using a lavalier mic
1.
Press , and select the input level.
• To change the setting, press the same key again while the parame-
ter appears enlarged.
• Select "AUTO" if you want the input level to be adjusted automati-
cally.
NOTE
■
Adjusting the side mic level (stereo width) of a mid-side mic capsule.
1.
When the mic capsule is connected, press , and select the
side mic level.
■
Monitoring audio while recording
1.
Connect headphones to the PHONES OUT jack.
2.
Use and to adjust the volume.
1
1
2

Zoom F1 Specifications

General

Type	Field Recorder
Audio Formats	WAV, MP3
Max Sample Rate/Resolution	96 kHz / 24-Bit
Power	2 x AAA Batteries, USB Bus Power
Battery Life	Up to 10 hours
Simultaneous Recording Tracks	2
Built-In Microphone	No
Input Channels	2
Output Channels	1
USB	1 x Micro-USB
Recording Media	microSD/microSDHC cards (up to 32 GB)
Dimensions	64 x 79.8 x 34 mm
Display	Monochrome LCD
Line Input	1 x 1/8" (3.5 mm) TRS
Headphone Output	1 x 1/8" / 3.5 mm TRS
Microphone Input	1 x 1/8" (3.5 mm) TRS
