Zoom F1 Quick Guide

2
Preparations
1.
Remove the battery cover, and insert batteries.
A ZOOM AD-17 AC adapter can also be used.
HINT
2.
Open the microSD card slot cover, and insert a microSD
card.
3.
Slide toward to turn the power on.
Slide toward HOLD to disable the keys and prevent misopera-
tion during recording.
HINT
4.
Set the language displayed.
Select the language: Press or
Conrm: Press
5.
Set the date and time.
Move cursor: Press or
Change value: Press or
Conrm: Press
Language and date and time settings can be changed later from the menu screen.
To open the menu screen, press
while pressing .
HINT
Unlock the cover
and pull it open

Zoom F1 Specifications

General

Type	Field Recorder
Audio Formats	WAV, MP3
Max Sample Rate/Resolution	96 kHz / 24-Bit
Power	2 x AAA Batteries, USB Bus Power
Battery Life	Up to 10 hours
Simultaneous Recording Tracks	2
Built-In Microphone	No
Input Channels	2
Output Channels	1
USB	1 x Micro-USB
Recording Media	microSD/microSDHC cards (up to 32 GB)
Dimensions	64 x 79.8 x 34 mm
Display	Monochrome LCD
Line Input	1 x 1/8" (3.5 mm) TRS
Headphone Output	1 x 1/8" / 3.5 mm TRS
Microphone Input	1 x 1/8" (3.5 mm) TRS
