14
Specications
Recording
media
SD cards, SDHC cards, SDXC cards (that conform to standards)
Inputs Inputs 1–6 Connectors XLR jack (pin 2 hot)
Input (mic) Input gain +12 dB - +75 dB
Input impedance 3 kΩ or more
Maximum input level +4 dBu
Input (line) Input gain −8 dB - +55 dB
Input impedance 5 kΩ or more
Maximum input level +24 dBu
Phantom power +24/+48V 10mA maximum for each channel
Equivalent input noise −127 dBu or less (A-weighted, +75 dB input gain, 150 Ω input)
Outputs Line output Connectors 3.5 mm stereo mini unbalanced output
Output impedance 100 Ω or less
Reference output level –10 dBV, 1 kHz, 10 kΩ load
Maximum output level +10 dBV, 1 kHz, 10 kΩ load
D/A dynamic range 95 dB typ (−60dBFS input, A-weighted)
Headphone output Connector 3.5 mm stereo mini unbalanced output
Output impedance 15 Ω or less
Maximum output level 100 mW + 100 mW (32Ω load)
D/A dynamic range 108 dB typ (−60dBFS input, A-weighted)
Recording
formats
When WAV selected
Supported formats 44.1/47.952/48/48.048/88.2/96/192 kHz, 16/24-bit/32-bit oat,
mono/stereo/2-8ch poly, BWF/iXML
Maximum simultaneous
recording tracks
14 (6 inputs x 2 (Linear and Floating) + LR mix)
6 (6 inputs (Linear or Floating) at Float(32bit) Mode, 192 kHz)
When MP3 selected
Supported formats 128/192/320 kbps, 44.1/48 kHz, ID3v1 tags
Maximum simultaneous
recording tracks
2
Recording
time
Using a 32 GB card
30:46:00 (48 kHz/24-bit stereo WAV)
7:41:00 (192 kHz/24-bit stereo WAV)
Timecode Connectors 3.5 mm stereo mini (Tip: IN, Ring: OUT)
Modes Off, Int Free Run, Int Record Run, Int RTC Run, Ext, Ext Auto Rec
(audio clock can be synchronized to timecode)
Frame rates 23.976 ND, 24 ND, 25 ND, 29.97 ND, 29.97 D, 30 ND, 30 D
Precision ±0.2 ppm
Allowed input level 0.2 – 5.0 Vpp
Allowed input impedance 4.6 kΩ
Output level 3.3 Vpp
Output impedance 50 Ω or less
Power AC adapter : DC 5V (supports USB bus power)
Sony
®
L-Series battery
4 AA batteries (alkaline, lithium or rechargeable NiMH batteries)
