15
Specications
Maximum number of
simultaneous effects
Amplier + 9 effects
User patches 240
Sampling frequency 44.1 kHz
A/D conversion 24-bit 128× oversampling
D/A conversion 24-bit 128× oversampling
Signal processing 32-bit
Frequency characteristics 20 Hz – 20 kHz (+1 dB/−2 dB) (10kΩ load)
Displays 5" TFT color LCD (800×480)
Dot-matrix LCDs (128×32) (6)
Inputs INPUT Standard mono phone jack
Rated input level: -20 dBu
Input impedance (line): 500 kΩ
RETURN Standard mono phone jacks (2)
Rated input level: -20 dBu
Input impedance (line): 1 MΩ
AUX IN Stereo mini jack
Rated input level: -10 dBu
Input impedance (line): 10 kΩ
Outputs Left/Right Standard mono phone jack
Maximum output level:
INST/LINE +11.4 dBu/+19 dBu (when output impedance 10 kΩ or higher)
PHONES Standard stereo phone jack
Maximum output level:
Line +11.4 dBu (when output impedance 10 kΩ or higher)
Headphones 24 mW + 24 mW (at 32Ω load)
SEND Standard mono phone jacks (2)
Maximum output level:
Line +11.4 dBu (when output impedance 10 kΩ or higher)
Input S/N 123 dB
Noise oor
(residual noise)
Left/Right INST/LINE −99.5 dBu/−92.5 dBu
SEND -99.0 dBu
MIDI IN/OUT 5-pin DIN jacks
Control input FP02M input
Power AC adapter: 12V DC, center plus, 2000 mA (ZOOM AD-19)
USB DEVICE Connector: USB2.0 Type-C / Supported cable: Type-C cable
GuitarLab: USB1.1 Full Speed
Audio Interface: USB2.0 High Speed, 44.1 kHz/32-bit 4in 4out
• Use cables for data transfer. USB bus power notsupported.
USB HOST Connector: USB2.0 Type-A / Standard: USB 2.0 High Speed
• Use a USB thumb drive.
REMOTE ZOOM BTA-1 or other dedicated wireless adapter
External dimensions 253 mm (D) × 495 mm (W) × 64 mm (H)
Weight 2.8 kg
• 0 dBu = 0.775 V
