Zoom G2 FOUR Quicktour

4
Using the EFFECT Screen and performing
On the EFFECT Screen, the effects and the amp used in the patch memory are shown in
order from the left.
EFFECT Screen
■
Turning effects on/off
■
Changing positions of shown effects
This effect can be used to adjust volume and wah with the expression pedal.
This sets the tempo in BPM (beats per minute) used by the rhythm, the looper, and delay and
modulation effects.
These show the order of the effects.

Zoom G2 FOUR Specifications

General

Rhythm Patterns	68
Simultaneous Effects	7
Sampling Frequency	44.1 kHz
A/D/A Conversion	24-bit
Rated Input Level	-20 dBu
Maximum Output Level	+5 dBu
Output Impedance	1 kΩ
USB Audio Interface	2 in / 2 out
Amp Models	22
Input	1/4" phone jack
Output	1/4" phone jack
Headphones	1/8" stereo phone jack
Power Supply	AA batteries or AC adapter
Frequency Response	20 Hz - 20 kHz
Input Impedance	470 kΩ
Expression Pedal	Yes
Inputs	1 x 1/4" (guitar)
Outputs	1 x 1/4"
Effect Types	79 (G2 FOUR) / 82 (G2X FOUR)
