Zoom R20 Supplementary Manual

Functions added in Version 2.0
Support for control surface
When using the R20 as a USB audio interface, the control surface feature can control DAW by operating buttons
and faders.
Contents
Functions added in Version 2.0 .............................................................................................................................2
Contents ..................................................................................................................................................................2
Using as the control surface .................................................................................................................................. 3
Setting the control surface ................................................................................................................................3
Setting the DAW .................................................................................................................................................4
Functions for each operator of R20 ..................................................................................................................4
Appendix .................................................................................................................................................................5
Block diagram ....................................................................................................................................................5
2

Zoom R20 Specifications

General

Type	Digital Multitrack Recorder
Simultaneous Recording Tracks	8
Sample Rate	44.1 kHz
Bit Depth	24-bit
EQ	3-band EQ per channel
Inputs	8 XLR/TRS combo jacks
Phantom Power	+48V
Effects	Reverb, Chorus, Delay
Storage	SD card (up to 1TB)
USB	USB 2.0
Display	4.3-inch color touchscreen
Power Supply	AC adapter
Outputs	2 x TRS, 1 x Stereo Headphone
