Zoomlion FE10 User Manual

Instruction for use of the forklift with the triple pivot battery
38
Code
Fault display
Possible causes
3, 1
Coil1 Driver Open/Short
1. The connected earthed load is open-or short circuited.
2. The connection terminal is contaminated.
3. The harness is damaged or the connection is wrong.
Main Open/Short
1. The coil of master contactor is open or short circuited.
2. The connection terminal is contaminated.
3. The harness is damaged or the connection is wrong.
3, 2
Coil2 Open/Short Driver
1. The connected earthed load is open-or short circuited.
2. The connection terminal is contaminated.
3. The harness is damaged or the connection is wrong.
EM Brake Open/Short
1. Earthed load open or short circuit.
2. The connection terminal is contaminated.
3. The harness is damaged or the connection is wrong.
3, 3
Coil 3Open/Short Driver
1. Earthed load open or short circuit.
2. The connection terminal is contaminated.
3. The harness is damaged or the connection is wrong.
3, 4
Coil 4 Open/Short Driver
1. Earthed load open or short circuit.
2. The connection terminal is contaminated.
3. The harness is damaged or the connection is wrong.
3, 5
PD Open/Short
1. Earthed load open or short circuit.
2. The connection terminal is contaminated.
3. The harness is damaged or the connection is wrong.
3, 6
Encoder Fault
1. Moor encoder fault.
2. The harness is damaged or the connection is wrong.
3. Check the motor monitor menu: Motor RPM
3.7
Motor Open
1. The wires U, V, and W of motor are open-circuited.
2. Cable damage or connection error.
3, 8
Main Contactor Welded
1. The contact of master contactor is bonded.
2. The connecting wire U of motor is in poor contact or open-circuited.
3. An alternating voltage path (as an external preliminary charging resistor) provides
the capacitor bank (B + end) with the current.
3, 9
Main Contactor Did Not Close
1. The master contactor is unclosed.
2. The master contactor is burn or in poor contact.
3. The external loading at the capacitor bank (B + terminal) prevents the capacitor bank
from charging.
4. B + fuse blown.
4, 1
Throttle Wiper High
1. The voltage at the sliding end of accelerator is too high.
2. Check the accelerator input of monitoring menu.
4, 2
Throttle Wiper Low
1. The voltage at the sliding end of accelerator is too low.
2. Check the accelerator input of monitoring menu.
4, 3
Brake Wiper High
1. The sliding end of brake potentiometer is under high voltage.
2. Check the input of the brake potentiometer of monitoring menu.
4, 4
Brake Wiper Low
1. The voltage at the sliding end of brake potentiometer is too low.
2. Check the input of the brake potentiometer of monitoring menu.
4, 5
Pot Low Overcurrent
a) The resistance value at the low end of potentiometer connected to the potentiometer
combination is too low.
b) Check the low-end output of monitoring menu potentiometer.
