Safety criterion for excavator
ZE205E/ZE230E OPERATION MANUAL
emergency exits.
Escape by the following steps (as shown in Figure 1-49):
1. Break the glass of the rear window with the hammer (1) hanging in upper right of the back of the cab.
2. Climb out from the rear window.
The rear window should not be broken unless it is used as an emergency exit.. After smashing the
glass, you should contact Zoomlion or Zoomlion dealer to replace the cracked glass as soon as possible.
Figure 1-48 Handrails and pedals
Figure 1-49 Emergency exits and escape tools
