Chapter One: Safety criterion for excavator
1.1 Safety signs
1.1.1 Location of safety signs
This machine uses the following warning signs and safety signs (as shown in Figure 1-1, Note: The
figures inside the circle are the illustrations corresponding to the figures inside brackets in the "safety signs"
text. For example:
○
1 → (1)). It is necessary to remind that they should be kept in correct place and always be
kept clean to ensure that the signage content can be clearly read. When cleaning the signs, do not use organic
solvents or gasoline, otherwise it would peel off the sign. If some of the signs are damaged, lost or can not
read normally, they should be replaced timely. See instructions or actual signs for details about the part
number of the signs, and make the order from Zoomlion, or Zoomlion dealers.
Figure 1-1 Location of safety signs
1. Precautions for the working device 2.Whole machine lifting figure 3.Precautions on cable handling 4. Engine warning sign
5. Rotation center sign 6..Regular maintenance and check table 7. Sign for prohibiting hoisting with the device
8. Precautions on adjusting the track tension 9.Tie point sign 10. Escape hatch 11.Sign for engine hood lock
12. Warning before the operation 13. Precautions during operation 14. Warning about operation and mobility of machine
15. Warning before standing up from the operator’s seat 16. Warning before leaving the machine 17. High-voltage warning
18. Warning for leaving the operator seat 19. Precautions for operation, inspection, transportation and maintenance
20. Drop warning 21. Prohibit from hot-wiring the machine 22 Maintenance of the air filter 23. Drop warning
24.Stop spinning while detecting and adjusting 25. Description of the use of emergency exits 26. Warning for closing the
window 27. Precautions when turning off the negative power supply 28. Precautions on the high-temperature coolant and
hydraulic oil 29. Precautions on using the accumulator 30 .Prohibit from entering the machine’s rotary area
Fig 1-1 Location of safety signs
