ZOTAC ZBOX
6
Getting to know your ZOTAC ZBOX
Front view
Refer to the diagram below to identify the components on the front of the ZBOX.
1. Power button
The power button turns the system ON and OFF.
2. MicroSD memory card slot
The built-in memory card reader supports Micro SDHC/SDXC cards to expand the storage
capabilities of the ZOTAC ZBOX.
3. USB 3.0 Type-C port
The type-C USB 3.0 port supports the SuperSpeed USB 3.0 devices. Use this port for USB
3.0 devices for maximum performance with USB 3.0 compatible devices.
4. USB 3.0 port
The USB 3.0 port supports the SuperSpeed USB 3.0 devices and is backwards compatible
with USB 2.0/1.1 devices. Use this port for USB 3.0 devices for maximum performance with
USB 3.0 compatible devices.
5. Combo Headphone/Microphone jack (3.5mm)
The combo headphone/microphone jack (3.5mm) is used to connect the system’s audio out
signal to amplied speakers, 3-pole headphones or 4-pole CTIA headphones.

Note: The combo headphone/microphone jack does not support the traditional microphone.
1
2 3
4
5
