Zotac ZBOX nano ID61 PLUS

3
ZOTAC ZBOX nano
Product specications
Chipset
• Intel HM65
Product Dimensions
• 127mm x 127mm x 45mm
Onboard CPU
• Intel Celeron 867
Onboard graphics
• Intel HD Graphics Family
• HDMI & DP output
Memory support
• One 204-pin SO-DIMMs DDR3-1333
• Up to 8 GB of memory
USB ports
• Two USB 2.0 ports & two USB 3.0 ports
Storage support
• SATA 6.0 Gb/s transfer rates
• Supports one 2.5-inch SATA HDD (support the device with max 9.5mm height)
• One eSATA port
Network support
• Gigabit (10/100/1000Mbps) LAN
• IEEE 802.3 compatible
WiFi/Bluetooth support
• Compliant with IEEE802.11b/g/n standard
• High speed wireless connection up to 150 Mbps
• Fully qualied Bluetooth v3.0
Audio
• 2-channel high-denition audio
• Jack-sensing compatible
• Optical SPDIF
Operating System support
• Microsoft Windows 7
• 32-bit and 64-bit support
IR receiver
• Support carrier frequencies 36k Hz
• Compliant with Win 7
