Figure3-1IndicatorsoftheZXHNF600Unit
Table3-1describestheindicatorsonthefrontpaneloftheZXHNF600unit.
Table3-1IndicatorsontheFrontPanel
Indicator
Status
Description
Off
Nopower
Power
Solidgreen
Poweron
Off
TheONTregistrationfailsorthesystemis
notpoweredon.
SolidgreenTheONTregistrationissuccessful.
PON
Flashinggreen
TheONTisbeingregistered.
Off
TheONTreceivedopticalpowerisnormal.
Solidred
TheopticaltransmitterofthePONinterface
ispoweredoff.
LOS
Flashingred
TheONTreceivedopticalpowerislower
thantheopticalsensitivityofthereceiver.
