Internet User Guide, ZTE H298N Last amended: 21/10/2014
9
Note: You can enable your internet service to more rooms by adding additional Ethernet cabled connections
between your router and your patch panel as shown in the diagram below:
A ‘wired’ connection using the patch panel (Using your house’s internal wiring)
continued...
LAN4 LAN3 LAN2 LAN1 WAN PhoneReset WPS
WLAN
USB2
PowerOn/Off
LAN4 LAN3 LAN2 LAN1 WAN PhoneReset WPS
WLAN
USB2
PowerOn/Off
INTERNET
PORT 1
BLUE
WAN PORT
INTERNET
PORT
INTERNET
PORT
LAN
PORTS
(1-4)
Internal
Wiring
Internal
Wiring
