6
Before using your phone Before using your phone
7
Battery usage
Battery installation
1. Remove the battery cover from
the unit.
2. Slide the battery into the slot
located at the bottom of the unit
and press until you hear the
“Click”.
Battery removal
1. To remove the battery, push down
on the top of the battery while
inserting your finger into the slot
and pulling up from the back of the
battery and slide it out.
2. Align the cover tabs with the slots
at the top of the device and slide
the battery cover back onto the
unit.
note If the battery is not installed
properly, the handset will not turn on
and/or the battery may detach during
use.
Battery charging
Power connection
1. Plug the AC Charger into a
standard outlet.
2. Plug the other end of the AC
Charger into the charging port on
your phone. The battery must be
installed in the device to charge
properly.
note
• When you charge the battery with
the phone powered o, you will
see a charging status screen. You
cannot operate the phone until it is
powered on.
Before using your phone
Handset description
1. Earpiece
2. OK key
3. Menu key
4. Send key
5. Speakerphone key
6. QWERTY keyboard
7. Microphone
8. Navigation key
9. Contacts menu
10. End key
11. Back Key
12. Delete key
13. Messages key
14. Music key
15. Schedule key
16. Headset port
17. Speaker
18. Camera lens
19. Charger port
20. Side volume key
21. Camera key
17
16
19
18
20
21
3
7
1
4
6
5
9
10
11
13
14
12
2
8
15
