1GE Dual Mode ONU User Manual
Ethernet Type
Set the Ethernet type of loopback packet.
Send Interval
Set sending Interval time of loopback packet.
Port Closing Time
Set how much time the port will be closed once detected
loopback.
Loopback Recovery Time
Set loopback recovery time.
3.6.5.2 Enable Configuration
This page allows user to enable or disable LAN port loopback feature.
Figure 3-41: Enable Configuration
Parameter
Illustration
Loopback Enable
Enable or disable LAN port loopback detection.
Alarm Enable
Enable or disable LAN port loopback alarm.
Portdislooped Enable
Enable or disable LAN port automatic recovery.
3.6.5.3 VLAN Configuration
This page allows user to set VLAN of loopback detection packet. After added VLAN, ONU
will send out loopback detection packets with the VLAN.
