ZXA10F660UserManual
Figure4-12DHCPServer
2.OntheDHCPServertab,conguretheparameters,aslistedinTable4-9.
Table4-9ParametersforDHCPServerConguration
ParameterDescription
LANIPAddressIPaddressoftheLANgroup(interfacesubnet)
SubnetMaskSubnetmaskoftheLANgroup
EnableDHCPServerToenableordisabletheDHCPserver
DHCPStartIPAddressStartingIPaddressallocatedbytheDHCPserver
DHCPEndIPAddressEndingIPaddressallocatedbytheDHCPserver
DNSServer1IPAddressIPaddressoftheDNSserver
DNSServer2IPAddressIPaddressoftheDNSserver
DNSServer3IPAddressIPaddressoftheDNSserver
DefaultGatewayIPaddressofthedefaultgateway
LeaseTimeLeasetimeoftheIPaddressbytheDHCPserver
3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.
–EndofSteps–
Result
TheDHCPserveriscongured.
4-14
SJ-20110718111034-001|2011-07-18(R1.0)ZTEProprietaryandCondential
