Chapter 3 Installation Preparation
3.1 Hardware Description
Front panel
Figure 3.1-1 Front Panel of the ZXHN H168N
Table 3.1-1 Descriptions of the LEDs on the Front Panel
Function Color Status Definition
USB Green
OFF
No device connected to the
USB port.
ON
A USB device is connected.
Flash
Data Transmission.
