ZTW Beast SL 45A User Manual

Function
LED
LED Status
Low voltage of the battery
Over-heat of the ESC and motor(95℃)
Sensorless motor
Red LED
Blue LED
Blue LED
Blinking
Blinking
ON
4
Sensorless Mode
When using a Sensoreless Brushless motor, the Blue motor wire A , Yellow motor wire B and
Orange motor wire C of the ESC can be connected with the motor wires freely. If the motor runs in
the opposite direction, please swap any two wire connections.
Connection to the Receiver
Black wire RX-
Red wire RX+6.0V
White wire RX-Signal
LED Indication
* When ESC are connected with the battery pack, the ESC can automatically identify the motor
type via indicated LEDs.
