Zummo Z10 - List of Components

A - 16
1.10. LIST OF COMPONENTS
Code
Description
0502004
BLADE SLIDE COVER
0502005
CUP SLIDE COVER
0503001
FEED PADDLE
0503003
FEEDER LEVER SHAFT
0503004A
FEEDER LEVER
0503005A
FEED PADDLE ROD
0504001A
GEAR BOX TYPE SX-50 i=36:1 (BOX)
0504002B
MOTOR 0,33CV 225v 50Hz
0504003B
MOTOR BIPHAS 0,33CV 110V-60Hz (FEET)
0504003C
MOTOR BIFAS 0.33CV 220v-60hHz
0504005
GEAR BOX POLEY (60XL 037)
0504006
PINION
0504007
BOLT & PINIONS WASHER
0504008
RACK
0504009
BOLT (UPPER CONNECTING ROD)
0504010
CONNECTING ROD
0504012
RACK SLIDE
0504013
PRESS PLATE FASTENER
0504014-1
CUP SLIDE
0504015A
BLADE SLIDE
0504016
CUP SLIDE BAR
0504019
BELT 190XL 037
0504020
PLASTIC WASHER 7,5/15 X 1,5
0504026
SHAFT (GEAR BOX SX-50)
0504A00
PRESS SET
0504B00
BLADE SHAFT
0504B04
BLADE SHAFT COTTER
0505003G
BLADE Z05 (GREY)
0505004G
BALL 80 (BRIGHT GREY)
0505005G
BALL 67 (DARK GREY)
0505006G
CUP 90 (BRIGHT GREY)
0505007G
CUP 75 (DARK GREY)
0505009A
CUP SHAFT
0505010A
FASTENING NUT WITH RAKED JOINT
0505010A-1
CUP NUT
0505010A-2
FASTENING NUT JOINT Ø20
0505011A
SQUEEZING TRAY SHAFT
0505016
PEEL EXTRACTING BANDS
0506002B
MICRO-COUNTER HOLDER
0506006/1
SQUEEZING TRAY MICRO CLAMP
0506007
MICRO (SHORT)
0506008
MICRO (LONG)
0506011
FUSE Ø5X20 6A
0506023
ELECTRIC LEAD (UL-CSA Standard)
Code
Description
10/10
SWITCH + LED LIGTH
10/21
CONDENSER 30 µF
10/25
CONDENSER 100µF
1000002A
WATER CONTAINER 16L
1000006
BLACK STICKER 200x200
1000007
BLACK STICKER 180X95
1000016
CAP Ø42mm
1001010
LOWER HINGE WASHER
1001015
COMPLETE MACHINE FOOT
1001016
MACHINE FOOT SCREW
1001026
RUBBER BASE (MACHINE FOOT)
1002003A
METHACRILATE WINDOW (2001)
1002006
WINDOW FRAME 190X208
1002009
DOOR GLASS (25-11-99)
1002011A
DRIP TRAY (SERIES 2002)
1002012A
DRIP GRILLE (SERIES 2002)
1002013
EXTERIOR GLASS FRAME (SILVATRIN
SILVER)
1002020
DOOR ADHESIVE
1002023
LOCK HANDLE
1002023-1
BLANK KEY
1002023-2
DOOR LOCK + SAFETY KEY
1002023-3
SELLER NUT 1/2
1003001
SQUEEZER SUPPORT
1003005A
LEFT CHANNEL
1003005A-1
COMPLETE LEFT CHANNEL
1003006A
RIGHT CHANNEL HOLDER
1003007A
RIGHT CHANNEL
1003007A-1
COMPLETE RIGHT CHANNEL
1003008
MACHINE ROOF SUPPORT SUPPLEMENT
1003010G
SQUEEZER ROOF(GREY)
1003012
FEED RAMP
1003013
LOWER BEADING
1003014G
SQUEEZING TRAY (GREY)
1003015
INTERIOR FILTER
1003016
FRONT
1003021
BACK ANCHOR
1003022
FEEDER SPRING SUPPORT
1003023
FEEDER SPRING
1003024B
SQUEEZER FRONT COVER
1003025
EXTERIOR FILTER TRAY (PLASTIC)
1003026
EXTERIOR FILTER TRAY HOLDER
1003027
EXTERIOR FILTER
1003028
LEFT CHANNEL GUIDE
