X10 SIP Paging Gateway User Guide
11
2. Overview
2.1 Product Overview
X10 SIP paging gateway is SIP enabled multifunctional IP audio device dedicated for
industry users. It can convert voice streams from a SIP paging system or IP PBX system to
analog sounds for background music, public address, intercom, etc. Based on the compact
hardware design, open standard SIP protocol support, rich functionality and high
performance.
2.2 Product Specifications
X10 SIP Paging Gateway Specifications
Amplifier Output
2x10W, 8Ω (4 pins)
Headset Output
3.5mm Jack
Microphone
3.5mm Jack
Power Input
DC 12V-3A Jack
Call button
Support 2 call buttons (switch
button)
Call button LED
Support 2 call button LED
indicators
Dry Contact
NO/NC contacts, max AC 125V-
1A, DC 60V-1A
