ZyXEL Communications AMG1202-T10A Quick Start Quide

O
NNECTION
SO
NNECTION
S
O
NNECTION
S
5
Hardware Connections
Remove any clear plastic covers from the AMG1202-T10A before
using it.
1. DSL: Use a telephone wire to connect this port to a telephone jack (or
the DSL or MODEM jack on a splitter, if one is already installed).
2. ETHERNET 1-4: Use an Ethernet cable to connect a computer to this
port for initial configuration and/or Internet access.
3. Use the power adaptor provided with your AMG1202-T10A to
connect an appropriate power source to this socket.
4. Push the power switch to the on position.
2
3
4
1

ZyXEL Communications AMG1202-T10A Specifications

Power

power input	9 V DC 0.85 A

Operating Environment

operating temperature	0°C to 40°C
operating humidity	20% to 85% RH
storage temperature	-20°C to 60°C
storage humidity	20% to 90% RH

Weight and Dimensions

item dimensions	175 x 117 x 31 mm
item weight	200 g
packing dimensions	295 x 145 x 37 mm
packing weight	250 g
