Dimension GS-2024
24-port Managed Layer 2 Gigabit Ethernet Switch with 2 SFP Slots
Specifications
System Specifications
Standard Compliance
• IEEE 802.3 10 Base-T Ethernet
• IEEE 802.3u 100 Base-Tx Ethernet
• IEEE 802.ab 1000 Base-T Ethernet
• IEEE 802.3z
• IEEE 802.3x Flow control
• IEEE 802.1d Spanning tree protocol
• IEEE 802.1w Rapid Spanning tree
protocol
• IEEE 802.1p Class of service,
priority protocols
• IEEE 802.1Q VLAN tagging
• IEEE 802.1x
• IEEE 802.3ad Port aggregation
Performance
• 48Gbps non-blocking switching fabric
• 35.7 million packet-per-second
forwarding rate
• Flexible design for both Gigabit
copper and Gigabit fiber connectivity
• 1488000pps forwarding rate for
1000 Base-T/1000 Base-X connectivity,
148800pps forwarding rate for
100 Base-Tx connectivity
• Wire-speed performance
MAC and Packet Buffer
• 8K MAC entries
• 4Mbits packet buffer
Traffic Management and QoS
• IEEE 802.1p
• 8 egress queues per port for different
types of traffic
• WRR (Weighted Round Robin)
scheduling for different prioritization
of packets
• SPQ (Strict Priority Queuing) for
highest priority packets to get best
service
• IEEE 802.1Q tag-based and
port-based VLAN
• 256 static VLAN, up to 4K
dynamic VLAN
• Support GVRP, automatic VLAN
member registration
• Supports jumbo frame, up to 9K Bytes
• Supports IGMP snooping
• Congestion control on all ports
• Rate limiting(Ingress rate)
- Allow bandwidth to be shaped in
steps at 64Kbps
- Supports 14 scales for incremental
rate limiting incrementally
Link Aggregation
• IEEE 802.3ad compliant
• Support LACP, static and dynamic link
aggregation
• Up to 4 aggregation groups
• 8 ports per group randomly selected
Redundancy for Fault Backup
• IEEE802.1w Rapid Spanning Tree
Protocol (RSTP) provides rapid
convergence of spanning tree
independent of spanning-tree timer
User Security and Authentication
• MAC filtering per port secures access
to each port
• Specific MAC forwarding per port:
only specified MAC addresses can
access the network (port lock)
• 802.1x port-based security, prevent
unauthorized client access to the
network
• Private VLAN provides security and
isolation between ports on a switch,
ensures that users can not snoop on
each other’s traffic
Network Administration Security
• User name/password required for
web/telnet/local console
administrators
• Two level security by specific SNMP
read/write community
Network Management
• Supports ZyXEL iStacking
TM
, up to 24
switches can be managed by one IP
• Web-based management
• Telnet CLI
• SNMP v2c
• RS-232c Local console
• IP management: static IP or
DHCP client
• RMON four RMON groups 1, 2, 3, 9
(history, statistics, alarms, and events)
for enhanced traffic management,
monitoring, and analysis
• Port mirroring: supports
Source/Destination/Both port mirroring
Hardware Specifications
Interface connections
• 24 100/1000 Base-T, auto-negotiation
and cross-over
• 2 shared SFP open slots
• 1 console port,
D-Sub 9 pin Female (DCE)
• 1 out-of-band management port, RJ-45
Physical Specification
• Dimensions:
440 (L) x 300 (D) x 445 (H) mm
• Weight: 4 Kg
Power Requirement
• Input voltage of AC: 100-240VAC,
50/60Hz
• Max power rating of AC: 50 Watt
Environmental Specification
• Operating temperature: 0°C~ 45°C
• Storage temperature: -25°C ~ 70°C
• Operating humidity: 10% ~ 90%,
non-condensing
